Premier Cabinet Series - Molding Overlay Collection

Molding Overlay Collection

Tall Base Cabinets 38 3/4" High

Construction Features

General

We state cabinet depth to the front of the doors, false fronts and drawer fronts as 21 3/4" or 18 3/4" deep.
Painted Cabinets have doors made from HDF.
Solid Cherry, Cherry Rustic, Maple or Oak wood for Dresser vanity and furniture - doors, drawer fronts, false drawer front, ends, face frame, sill, legs, side moldings and top moldings
Solid Cherry, Cherry Rustic, Maple or Oak wood for Vanity - doors, drawer fronts, false drawer front, face frame, side moldings and top moldings.
Solid Cherry, Cherry Rustic, Maple or Oak wood for Mirrored Cabinet, Framed Mirror - doors, crown molding, sill, side moldings and top moldings.
Solid Cherry, Cherry Rustic, Maple or Oak wood for Linen Cabinetry - doors, drawer fronts, face frame, crown molding, skirt, side-moldings and top molding.
Soft close fully-concealed European style hinges.
Natural finish interior, shelves and drawers.
Backs on dresser vanities, vanities, linen cabinets, mirrored cabinets and framed mirrors are 1/8" Maple laminate hardboard.
Crown molding adds 1 3/8" to stated depth and 2 7/8" to stated width for Molding Overlay Construction. Crown molding adds 5/8" to stated depth and 2 7/8" to stated width for Overlay Construction.
Durable catalyzed varnish finish.

Plywood Specifications

Ends of Cherry, Cherry Rustic, Maple and Oak 1/2" veneer core plywood includes a smooth and voidless MDF cross band next to the face and back veneers which improves the veneer surfaces.

Drawer

English dovetailed, solid 5/8" Maple wood drawer boxes with 5-piece construction.
Tandem full extension, undermount, soft-closing drawer glides (or Equivalent).
Drawer bottoms are 1/4" birch veneer plywood.

Vanity & Base

Ends of Cherry, Cherry Rustic, Maple and Oak 1/2" veneer core plywood includes a smooth and voidless MDF cross band next to the face and back veneers which improves the veneer surfaces.
Door hinges are concealed soft-close with 108 degree opening with integrated soft close door dampers.
Cabinet framing parts and corner blocks of 3/4" thick hardwood.
Sink door pairs have no center stile to limit plumbing access.
Vanity tops are not included with vanity or base price.
Vanity bottoms are 1/2" plywood.
Tall 33 1/2" height.

Installation Instructions

Add To
Project Queue

RE1221NM

12" Center Tall Base Cab. 4 Drwr

Dimensions: 12"W x 21³⁄₄"D x 40¹¹⁄₁₆"H

Options - Select at Right

Skirt: N/A (Standard)

Drawing represents this model's configuration but may not be for the exact width, door style or trim.

To order this model, take a print of this page, along with your Door Style and Wood-Color Selection, to your local Showroom (see Dealer Locator to select a Showroom in your area).
