We state cabinet depth to the front of the doors, false fronts and drawer fronts as 21 3/4" or 18 3/4" deep.
Painted Cabinets have doors made from HDF.
Solid Cherry, Cherry Rustic, Maple or Oak wood for Dresser vanity and furniture - doors, drawer fronts, false drawer front, ends, face frame, sill, legs, side moldings and top moldings
Solid Cherry, Cherry Rustic, Maple or Oak wood for Vanity - doors, drawer fronts, false drawer front, face frame, side moldings and top moldings.
Solid Cherry, Cherry Rustic, Maple or Oak wood for Mirrored Cabinet, Framed Mirror - doors, crown molding, sill, side moldings and top moldings.
Solid Cherry, Cherry Rustic, Maple or Oak wood for Linen Cabinetry - doors, drawer fronts, face frame, crown molding, skirt, side-moldings and top molding.
Soft close fully-concealed European style hinges.
Natural finish interior, shelves and drawers.
Backs on dresser vanities, vanities, linen cabinets, mirrored cabinets and framed mirrors are 1/8" Maple laminate hardboard.
Crown molding adds 1 3/8" to stated depth and 2 7/8" to stated width for Molding Overlay Construction.
Crown molding adds 5/8" to stated depth and 2 7/8" to stated width for Overlay Construction.
Durable catalyzed varnish finish.
Plywood Specifications
Ends of Cherry, Cherry Rustic, Maple and Oak 1/2" veneer core plywood includes a smooth and voidless MDF cross band next to the face and back veneers which improves the veneer surfaces.
Drawer
English dovetailed, solid 5/8" Maple wood drawer boxes with 5-piece construction.
Tandem full extension, undermount, soft-closing drawer glides (or Equivalent).
Drawer bottoms are 1/4" birch veneer plywood.
Vanity & Base
Ends of Cherry, Cherry Rustic, Maple and Oak 1/2" veneer core plywood includes a smooth and voidless MDF cross band next to the face and back veneers which improves the veneer surfaces.
Door hinges are concealed soft-close with 108 degree opening with integrated soft close door dampers.
Cabinet framing parts and corner blocks of 3/4" thick hardwood.
Sink door pairs have no center stile to limit plumbing access.
Vanity tops are not included with vanity or base price.
Vanity bottoms are 1/2" plywood.
Tall 33 1/2" height.
Dresser Vanity, Wall Mount Vanity, Linen Tower & Base Tower
FEATURES ARE THE SAME AS VANITY FEATURES EXCEPT FOR THE FOLLOWING:
Dresser vanity, linen tower and base tower models have 9" legs mounted to a bottom sill. Wall Mount vanity, linen tower and base tower models do not have legs.
Standard with Raised Panel Ends. The Raised Panel style will be Ridgefield when the Ridgefield or Villa door style is chosen; will be Shaker when the Edgewood, Fairfax, Shaker, Old Town, or Shaker Door style is chosen; will be Wilton when the Wilton door style is chosen; and will be Prestige when the Prestige or any remaining Door style is chosen.
Maple painted cabinets with raised panel ends have the end panels made from High Density Fiberboard (HDF) to provide a more stable panel.
Base Tower with 1 door has 1 adjustable shelf.
Cabinet interiors have a natural finish to brighten the inside for storage use except on glass door models where the interior is completely finished.
All open areas are stained and finished.
To install inside standard 3/8" base molding on models with legs, use a belt sander to remove about 1/4" from the back of each back leg.
Linen Tower - Base can be standard linen cabinet base, with skirt and toe board, or can be 9" legs mounted to a bottom sill. The height with standard base is 61" and with 9" legs and sill is 67". The height of the Wall Mount Linen Tower is 57 1/8".
All Linen Tower models have beveled glass in the top door. Two-door models have 1 fixed and 3 adjustable shelves; One-door with drawer stack models have 1 fixed and 2 adjustable shelves. The crown molding with plywood insert to form top is included.
All Linen Tower Models - The crown molding with plywood insert, to form the top, is included.
All Linen Tower Models - All open areas or areas behind a glass door are stained and finished.
All Linen Tower Models - Glass is 3/16" clear glass with beveled edges. Optional Reeded Glass is 3/16" thick.
Dimensions do not include crown or sill. Dimensions do not include crown.
Options - Select at Right
Drawing represents this model's configuration but may not
be for the exact width, door style or trim.
To order this model, take a print of this page, along with your
Door Style and Wood-Color Selection, to your local Showroom (see Dealer Locator to select a Showroom in your area).
